The main purpose
Under laboratory conditions, it is used to evaluate the electrostatic properties of fabrics or yarns and other materials after triboelectric charging.
Instrument characteristics
1. Randomly display peak voltage, friction band voltage and time.
2. The peak voltage is automatically locked.
3. Automatically measure the decay time.
Technical indicators
1. Electrostatic voltage test range: 0～10KV, accuracy: ≤±1%
2. Drum size: outer diameter (150±1) mm, width (60±1) mm, rotating speed: (400±1) r/min,
3. Friction time: adjustable from 0 to 99.99s (test set at 1min)
4. Half-life time range: 0～99.99s
5. The size of the friction cloth: (150±1)mm×(25±1)mm, the pretension is: (4.9±0.1)N
6. Sample size: (80±1)mm×(50±1)mm
7. Dimensions of the host: 450mm×315mm×320mm
8. Dimensions of the electric control box: 450mm×256mm×185mm
9. Working power supply: AC220V 50Hz 200W
10. Weight: about 50kg
Applicable Standards
FZ/T 64082-2021 Scrim for filter media
GB/T 12703.5-2020  Textiles- Test methods for electrostatic propensity一
Part 5:Test method using rotary mechanical friction

GB/T 24249-2009    Antistatic fabric for cleanroom garment system

GB/T 6719-2009 Specifications for bag house
